7500 psi Modules

CALIBER®

Premium offers a complete line of fluid end modules and components that are manufactured to OEM specifications and interchangeability. We offer 7500 psi designs for all major pumps. Our Caliber modules have forged high-tensile strength steel and are machined to precise engineering tolerances. Each forging is machined, and heat treated to maintain the best physical properties inside the module and on the surface, thus minimizing washing and stress cracking.

We provide fluid ends for the following brands*

  • Emsco

  • Gardner Denver

  • Ideco

  • National
  • Oilwell
  • Lewco

*Available with Sur-Lock Quick Change Valve Covers and Liner Retention Systems

7500 psi Modules

Manufacturer Pump Model OEM Mission L SW Style Premium Caliber *Premium Caliber VoV
Bomco, Hong Hua F-1600 N/A N/A F-7500 N/A N/A
HHF-2400 N/A N/A N/A HP-7500 N/A
Emsco F-1600 FE-7500 FE-7500 F-7500 FP-7500 FX-7500
FB-1600 FE-7500 FE-7500 F-7500 FP-7500 FX-7500
FC-1600 FE-7500 FE-7500 F-7500 FP-7500 FX-7500
Gardner Denver PZ-2400 N/A N/A N/A GP-7500-24 N/A
PXL GX-7500 N/A GP-7500-PX N/A DX-7500
PZ-11 GX-7500 N/A GP-7500-PZ N/A DX-7500
PZ-10 GX-7500 N/A GP-7500-PZ N/A DX-7500
Ideco T-1600 N/A N/A N/A IP-7500 N/A
Lewco-Cameron W-1712 N/A N/A LP-7500-W17 N/A N/A
WH-1612 N/A N/A LP-7500-WH16 N/A N/A
W-2215 N/A N/A LP-7500-W22 NP-7500 N/A
W-2214 N/A N/A LP-7500-W22 NP-7500 N/A
WH-2214 N/A N/A LP-7500-WH22 N/A N/A
National 12-P-160 PE-7500-12P MXL-7500 N-7500-12P N/A N/A
14-P-220 PE-7500-14P ML-7500 N-7500-14P NP-7500 N/A
Oilwell A-1700-PT N/A N/A PS75-A17 N/A N/A
Weatherford Eweco
(Ellis Williams)		 E-2200 WP-7500-22 N/A WP-7500-22 N/A N/A
EH-1600 WP-7500-16 N/A WP-7500-16 N/A N/A
EQ-2200 WP-7500-16 N/A WP-7500-16 N/A N/A
Wirth TPK-2200 TP-7500 N/A N/A N/A N/A
TPK-1600 TP-7500 N/A N/A N/A N/A
White Star Q-2450 N/A N/A N/A WSP-7500 N/A
Q-1850 N/A N/A N/A WSP-7500 N/A
